Type：gas-filled thermocouple
Illustrate：Application It is filled with nitrogen or other gas to prevent it from corrosive gas in order to extend its life expectancy. It is necessary temperature-measuring device for 300 thousand tones synthetic ammonia production equipments.
Gas-filled Thermocouple
Application
It is filled with nitrogen or other gas to prevent it from corrosive gas in order to extend its life expectancy. It is necessary temperature-measuring device for 300 thousand tones synthetic ammonia production equipments.
Main Technical Parameters
Electric outlet: M20X1.5, NPT1/2
Accuracy Class: Ⅰ、Ⅱ
Protection Class: IP65
Nominal Pressure: normal pressure
Type & Specification
| Type | Graduation | Measuring Range | Flow Speed | Specification | |
| d | Lx1 | ||||
| WRPC-430 | S | 0~1300 | GH3039 | ∮2.5 | 300x150 |
| WRP2C-430 | High Al Content | 350x200 | |||
| 400x250 | |||||
1) We may provide different class thermocouples as user’s demand ;
2) We also produce protection tube of other material
