Type：CX-IPE-1710、CX-GPE-1711、CX-GPE-1712、CX-GPE-1713
Illustrate： CX-IPE-1710、CX-GPE-1711、CX-GPE-1712、CX-GPE-1713 IndustrialPHElectrode ModelNo.:CX-IPE-1710 Technicalparameters: Measuringrange:0-14pH Temperaturerange:0-95％ Compressivestrength:0.6MP Connection:BNCand“Y”Ins..
CX-IPE-1710、CX-GPE-1711、CX-GPE-1712、CX-GPE-1713
Industrial PH Electrode
Model No.: CX-IPE-1710
Technical parameters:
Industrial PH Electrode
Model No.: CX-IPE-1710
Technical parameters:
| Measuring range: 0-14pH | Temperature range: 0-95％ |
| Compressive strength: 0.6MP | Connection: BNC and “Y” Insert |
| Dimensions: Diameter 12×120, 150, 210mm | |
|
Features: It adopts gel dielectric and solid dielectric double liquid junction structure, which can be directly used in the chemical process of the high-viscosity suspension, emulsion, the liquid containing protein and other liquids, which are easy to choke. There is no need for additional dielectric and there is a little amount of maintenance. It adopts BNC connector, which can be replaced by any electrode from abroad. For the electrode length, there are 120,150 and 210 mm available. According to different needs, they are optional. It can be used in conjunction with 361 L stainless steel sheath or PPS sheath. Scope of application: Chemical medicine on-line monitoring, chrome-removing line, dyes, pigments, mining, pulp mills, starch, mud, sugar, high viscosity suspensions, emulsions, the solution containing proteins, etc. Technical parameters: |
|
|
CX-GPE-1711 Glass PH Electrode Measuring range: 0-14PH Temperature range: 0-90 ℃ Features and range: Glass casing, gel KCL special waterproof connector, semi-circular-sensitive membrane, easy to clean, used for general industrial laboratory occasions. |
|
|
CX-GPE-1713 Glass PH Electrode Measuring range: 2-12PH Temperature range: 5-80℃ Features and range: Tapered sensitive membrane, which can be used for PH value testing of soil, meat, fruits, etc. |
|
